RAVEN™
Introducing RAVEN: Handheld “Smart” X-ray Imager
The Raven handheld imager provides outstanding mobility, enhancing threat detection across various environments.
Its lightweight and ergonomic design optimizes user efficiency, while its advanced imaging technology, multifunctional detection capabilities,
and AID Toolset facilitate the rapid identification of concealed threats. The Raven is an essential asset for mobile security operations.
The Raven handheld imager provides outstanding mobility, enhancing threat detection across various environments.
Its lightweight and ergonomic design optimizes user efficiency, while its advanced imaging technology, multifunctional detection capabilities,
and AID Toolset facilitate the rapid identification of concealed threats. The Raven is an essential asset for mobile security operations.
Key features
Modern Design
The RAVEN handheld imager boasts a modern design
that enhances operational experience and
effectiveness through ergonomics. Navigation buttons
are designed for easy use, even when wearing gloves.
Advanced Imaging Technology
RAVEN's cutting-edge X-ray optical engine provides detailed imaging with enhanced depth perception.
The advanced X-ray beam technology enhances visual depth and clarity, delivering top-notch image quality.
The large, vibrant, and rugged display ensures superior visibility in any field condition, including direct sunlight.
Multi-Detection Capabilities
In addition to unrivalled backscatter and transmission X-ray imaging,
RAVEN can be enhanced to identify radioactive isotopes, lead-lined
compartments, gold, and platinum during a scan. RAVEN also offers
material discrimination and AID Toolset to detect guns and other
anomalies, aiding operators in drug interdiction and counterterrorism
missions.
Compact and Versatile
Its slim design enables usage in tight spaces, and handles positioned behind the detector enhance
user safety.
Power and Flexibility
The device stays powered with hot-swappable batteries and features clearly visible warning and
indicator lights to ensure safe operation. Additionally, it offers convenient onboard battery charging.
Connectivity
Advanced options including WiFi, GPS, USB-C, Ethernet, Bluetooth, and optional 4G/5G cellular communication enhance usability by enabling seamless data transfer,
remote connectivity, precise location tracking,
and versatile wired connections for continuous operation.
Intelligent and Fast
RAVEN combines the latest in imaging technology with powerful AID Toolset to efficiently
reveal hidden threats in a wide range of applications.
Detect threats on the go.
The Raven handheld imager's mobility allows for efficient threat detection in various environments, including confined spaces and remote locations. Its lightweight, ergonomic design ensures ease of use, while the advanced imaging technology and AID Toolset enable quick identification of hidden threats, making it an invaluable tool for on-the-go security operations.
Raven Features
Discover the innovative features of the Raven Handheld Imager. Interact with our detailed visual rendering to explore each feature and see how Raven can enhance your imaging and multifunctional detection experience.
Buttons: 4-way Navigation and 2-way selection buttons on each handle allow seamless interaction with software without removing gloves.
Display: High resolution 1200x1980 FHD+ Display with antiglare/antireflective coating.
Processing Power: 8-core processing handles simultaneous Bx/Tx data collection with 1000px/raster images.
I/O: Easy access for wall power and USB-C connectivity, wired ethernet (via adapter), wifi, Bluetooth, gps and more.
Indication Lights: Easy visualization of power and scan states via LED light bars on either side of the screen and each handle.
Pistol Grips: Ergonomic and easy hold pistol grips and triggering for long scan comfort. Configurable single/dual trigger capability.
Sunshield: Removable sunshield snaps on/off and rotates to provide protection from the sun.
DTX Ports: Dual DTX adapter ports to mount up to 2 DTX accessories for transmission images; TX panel options also available.
Wide Area Detector: The best detector on the market means you continue to see clearer, deeper, with less constraints.
Flashlight: Super bright LED flashlight to help navigate in dark areas.
Powerful Upgrades: Add upgrades like PbID (lead trap detection), MatID (material discrimination), and more.
X-ray Beam: Full 85 degree + field of view sees everything in single pass.
Line Lasers: Two red line lasers positioned in beam for precision alignment and targeting.
Access / Expansion: Access to SD memory expansion card slot, onboard battery, cellular module (SIM card), and other hardware reset options.
Camera: 13MP color camera.
| Specification | Raven™ Handheld Imager |
 Nighthawk™ BTX |
Nighthawk™ HBI |
|---|---|---|---|
| X-ray Source | 140kV / 160kV | 120kV / 140kV | 120kV / 140kV |
| Size | 10.9" x 8.9" x 6.4" [278mm x 227mm x 162mm] or smaller | 11.1" x 7.8" x 10.9" [282mm x 199mm x 278mm] or smaller | 8.5" x 6.5" x 9.1" [215mm x 166mm x 231mm] or smaller |
| Weight | 11.5 [5.2kg] - 12lbs [5.5kg] | 9.5-10.7 lbs [4.3-4.8kg] | 8.1-9.4lbs [3.7-4.3kg] |
| Display | 7" FHD LCD, 2500nits | 6" LCD, 700nits | 6" LCD, 700nits |
| Backscatter Penetration | 11-13mm | 6.5-10 mm | 6-9mm |
| Resolution | .5 lp/mm; Resolves 1.0mm Wire | .25 lp/mm; Resolves 2.0mm Wire | .33 lp/mm; Resolves 1.5mm Wire |
| Operating Conditions | -4°F to 140°F (-20°C to 60°C) | -4°F to 140°F (-20°C to 60°C) | -4°F to 140°F (-20°C to 60°C) |
| Battery Life | Up to 8 hours, hot-swappable; onboard charging via wall adapter | 4-6 hours (120kV), 3-5 hours (140kV) | 5-6 hours (120kV), 4-5 hours (140kV) |
| Connectivity | WiFi, Bluetooth, Ethernet, Celluar (via optional upgrade with customer provided dataplan/SIM), GPS, USB-C † | WiFi, Bluetooth, GPS, USB-C | WiFi, Bluetooth, GPS, USB-C |
| Camera | 13 MP color | 5 MP color | 5 MP color |
| Special Features | Pb trap detection (PbID), AI Tools and machine learning (featuring automatic Gun detection and more), MatID (material discrimination for Bx and Tx scans), RadID (radioactive material detection), PmID (Precious metals automatic detection), custom body colors | Pb trap detection (PbID), WINGBAR Tablet | Pb trap detection (PbID), WINGBAR Tablet |
| Key Tx Imaging Accessories | RAVEN DTX, RAVEN-PNL | NIGHTHAWK DTX | NIGHTHAWK DTX |
